Summary

Kobi Toolkit v2027 for AutoCAD is a productivity add-on that adds over 20 specialized tools to Autodesk AutoCAD and Civil 3D. Unlike writing custom LISP routines or searching for scattered scripts online, Kobi Toolkit bundles nine tool sets into one integrated package. It is compatible with AutoCAD and Civil 3D versions 2021 through 2027, as well as BricsCAD V22 to V26.

The installation process is straightforward. Download the installer from the KobiLabs website. Close AutoCAD completely before running the installer. Run the installer as Administrator. The setup wizard will detect your installed AutoCAD versions and offer to install for each.

After installation, launch AutoCAD. The Kobi Toolkit ribbon tab appears automatically. If it does not,  type NETLOAD in the command line and manually load the KobiToolkit.dll file from the installation folder.

The toolkit requires a license. A free trial is available. To activate, click the “License” button in the ribbon, enter your email and license key, or request a trial key. The trial provides full functionality for a limited period.

Understanding The Dashboard

Kobi Toolkit does not have a separate dashboard. Its tools are integrated directly into the AutoCAD ribbon. The “Kobi Toolkit” tab appears alongside the native AutoCAD tabs (Home, Insert, Annotate, etc.).

The ribbon is organized into nine panels, each grouping related tools:

• Sheets Panel: Tools for batch publishing, sheet renaming, sheet list export, and drawing property manipulation.
• Blocks Panel: Tools for block counting, block renaming, attribute extraction, and block replacement.
• Layers Panel: Tools for layer merging, layer purging, layer state management, and layer renaming.
• Text & MText Panel: Tools for text case conversion, text find/replace, text alignment, and numbering.
• Dimensions Panel: Tools for dimension scaling, dimension text editing, and dimension style management.
• Tables Panel: Tools for table formatting, data extraction, and Excel import/export.
• Coordinates Panel: Tools for point coordinate export, point numbering, and coordinate labeling.
• Selection Panel: Tools for selecting objects by property, filtering, and counting.
• Settings Panel: Configuration options for default behaviors, output formats, and user preferences.

Each tool opens a dialog box or executes immediately. Most tools include preview modes showing what will change before applying.

Creating First Project

It works within existing AutoCAD drawings. There is no separate project file. Your “project” is any DWG file open in AutoCAD.

• Step 1: Open a Drawing: Open an AutoCAD drawing that contains sheets, blocks, layers, or text you want to process. A typical use case is a set of construction drawings with 50+ sheets.
• Step 2: Batch Rename Sheets: Click the “Sheets” panel, then “Rename Layouts”. The dialog shows all layout tabs. Select the ones to rename. Enter a prefix (e.g., “A-“) and suffix, or use find/replace. Click Apply. All selected layout names update instantly.
• Step 3: Count Blocks: Click the “Blocks” panel, then “Block Count”. The tool scans the drawing and displays a table of all block names and their counts. You can export this table to Excel or insert it as an AutoCAD table.
• Step 4: Export Point Coordinates: If your drawing has survey points or structural grid intersections, select them. Click the “Coordinates” panel, then “Export Points”. Choose CSV or TXT format. The tool exports all selected point coordinates.

Common Workflow Steps

1. Batch Publishing Multiple Layouts to PDF

Open the drawing with multiple layouts. Click Sheets panel → Batch Publish. Select the layouts to publish. Choose PDF as output format. Set paper size and other plot settings. Click Publish. The tool generates individual PDF files for each selected layout, saving hours of manual plotting.

2. Merging Redundant Layers

Open a drawing with layer clutter (e.g., “Layer1”, “Layer2”, “Layer3” that should all be “Walls”). Click Layers panel → Merge Layers. Select the source layers to merge. Select the target layer. Click OK. All objects on source layers move to the target layer. Source layers are purged.

3. Renaming Blocks Across the Drawing

Open a drawing where block names are inconsistent. Click Blocks panel → Rename Blocks. Select blocks to rename. Enter new name or use find/replace. Click Apply. All instances of the block update to the new name. Attributes are preserved.

4. Extracting Attribute Data to Excel

Open a drawing with attributed blocks (title blocks, equipment tags, door schedules). Click Blocks panel → Extract Attributes. Select blocks to extract. Choose which attributes to include. Click Export. The tool creates a CSV file ready for Excel. This replaces manual data entry for schedules.

Exporting Files

It exports data in several formats, integrated with AutoCAD’s native export commands.

1. Block Counts to CSV: The Block Count tool includes an “Export to CSV” button. The CSV can be opened in Excel for further analysis or billing.
2. Attribute Data to Excel: The Extract Attributes tool exports directly to CSV format. The file includes column headers matching attribute tags.
3. Point Coordinates to TXT/CSV: Export Points tool supports comma-delimited (CSV) and space-delimited (TXT) formats. Coordinates can be in world UCS or current UCS.
4. Sheets List to Excel: Sheets panel → Export Sheets List creates a CSV of all layout names, plot settings, and custom properties. This is useful for project management and sheet set documentation.

For DWG export, use native AutoCAD commands (SAVEAS, EXPORT). It does not replace these; it adds data extraction capabilities.

Troubleshooting

“Kobi Toolkit ribbon does not appear”

Type CUI in AutoCAD command line. In the Customize User Interface dialog, look for “KobiToolkit.cuix” in the partial customization files list. If missing, click “Load Partial Customization File” and navigate to the installation folder. Restart AutoCAD.

Tool returns error or does nothing

Some tools require specific object selections. For example, the Block Count tool requires at least one block in the drawing. The Export Points tool requires selected points. Ensure you have selected appropriate objects before running the tool.

Batch Publish produces blank PDFs

Check that each layout has a valid plot configuration. Open each layout, type PAGESETUP, and verify that a printer/plotter is selected and paper size is correct. The Batch Publish tool uses the saved page setup for each layout.

Excel export opens with garbled text

The CSV files are encoded in UTF-8. Excel on older Windows versions may open UTF-8 files incorrectly. Workaround: Use Excel’s “Data → From Text/CSV” import instead of double-clicking the file.

Toolkit stops working after AutoCAD update

AutoCAD updates can break add-ins. Download the latest Kobi Toolkit version from the KobiLabs website. Reinstall over the existing installation. Configuration and licenses are preserved.

Productivity Tips

1. Set up default export folders: In Kobi Toolkit Settings, specify default paths for CSV exports, PDF output, and log files. This saves browsing to the same folder every time.
2. Use batch publish for transmittals: Before sending drawings to clients, use Batch Publish to create PDFs. Sort layouts by sheet number. The output PDFs will be named using layout names.
3. Rename blocks before counting: If blocks have inconsistent names (e.g., “Door-36” vs “Door36”), use Rename Blocks first to standardize names, then use Block Count for accurate totals.
4. Merge layers before final deliverable: Architects and engineers often request drawings with minimal layers. Use Merge Layers to combine all annotation layers into a single “Text” layer before sending.
5. Extract attributes for schedules: For door, window, and finish schedules stored as block attributes, use Extract Attributes instead of manual data entry. The exported CSV can be formatted in Excel and inserted back as a table.
6. Use selection filters for complex edits: The Selection panel includes tools to select objects by layer, color, linetype, or property. Combine selections with native AutoCAD commands for batch edits.

Best Companion Tools

AutoCAD Sheet Set Manager (SSM): Works alongside Kobi Toolkit’s Sheets panel. Use SSM for sheet organization; use Kobi for batch publishing and sheet renaming.

Excel: The primary destination for attribute extraction, block counts, and point coordinates. Use Excel’s Power Query to automate processing of exported CSV files.

Notepad++: For editing exported TXT coordinate files before re-importing. Notepad++ handles large files better than Notepad.

Bluebeam Revu: For PDF markup. It exports PDFs; Bluebeam reviews them. The workflow is standard in construction document management.

AutoCAD native commands: It does not replace native commands. Use LAYER for layer management, BLOCK for block creation, PLOT for single-sheet plotting. Use Kobi for batch operations on multiple objects.

Conclusion

Kobi Toolkit v2027 for AutoCAD is a force multiplier for AutoCAD users who perform repetitive tasks daily. The software does not add new design capabilities. Instead, it automates the housekeeping tasks that consume time: renaming sheets, counting blocks, extracting attributes, merging layers, batch plotting, and exporting coordinates.

For a CAD manager setting up project standards across dozens of drawings, the toolkit saves hours. For an engineer preparing transmittal PDFs, batch publishing reduces clicks from hundreds to a few. For a detailer extracting door schedules from block attributes, the CSV export replaces manual typing.

The toolkit’s strength is its integration. Tools are accessible from the ribbon, understand AutoCAD objects, and respect drawing units. The learning curve is shallow most tools are self-explanatory. The price is reasonable compared to the time saved.
